Talkpod® A36plus MAX 144/430MHz Dual Band Transceiver includes NA-771 Antenna and Earpiece

Talkpod® A36plus Multi-Function Dual Bander with Color Display, Rugged and Basic 2M with Powerful Audio. Talkpod radios are built tough, and the A36plus – Talkpod's most economical 2M – is no exception. This military rugged rig offers water resistance and superior protection against dust and dirt (IP54). Compact, rugged and with plenty of power, the A36plus is ideal for basic, on-the-go ham operations.

Key Features
512 Channels (Each A/B has 256) • Dual-Band Analog FM HAM (Amateur Radio Service) Two-Way Transceiver •V/V,U/U,V/U Dualwatch • Pre-Programmed for HAM • Tru-Power VHF 5/2/0.5 Watts, UHF 5/2/0.5 Watts •  IP54 Water Jets Rated • Extended-Capacity 3200mAh (23.68 Wh) Li-ion Battery (*Optional TBL12) • Part 15B FCC (2ADQZGMRS1) Certification • Wide 7-Band Receive Range with AM AIR Band & Broadcast FM Radio (w/ 20 Memories)  • Memory & VFO Modes (Tx locked to HAM frequencies) • Wide & Narrow Bandwidth • DTMF Keypad • Repeater Reverse & Talk-Around Functions • 50 CTCSS PL Tones & 105 DCS Privacy Codes (Independently Front-Panel Programmable) • CTCSS/DCS Scanning • 1.44 inch Color Display • 16 Full Keypad (w/ Auto-Lock) • 2 Programmable Function Side-Keys • 2.5 kHz Tuning Steps • SOS Emergency Top Button • Battery Saver • Time-Out-Timer (w/ alarm) • 8-Character Alpha Channel Names • Type-C Connector • Voice Announce (English or Chinese) & Key Beeps (optional) • 10 Squelch Levels • BCL, VOX, SideTones, DTMF & ANI PTT-ID, Roger Beep • 8″ High-Gain Dual-Band Antenna Tuned for HAM Bands (removable) • Wrist Strap • Belt Clip • English Manual • Full Line of Accessories

Tx Range (MHz): 136-174 VHF • 400-512 UHF – Tx Locked at GMRS bands for USA market
Rx Range (MHz): 76-108 FM Broadcast Radio • 108-136 AM AIR BAND • 136-180 FM VHF • 200-260 FM VHF • 350-400 FM UHF • 400-520 FM UHF

Special Function
● Color display & UI, Multilingual
● Private call, scrambling can realize advanced private call
● Shake dizzy, Shake fraud, Shake up
● Smart frequency breaking, OTA replication frequency
● Can edit independent identity ID and personalized name
● Each channel has an editable name, which makes it easier to call contacts & groups
● Each A/B has 256 channels, maximum of 512 channels of stored
● DTMF、Cross frequency span
● “MDC1200” and other call end tones
● Support Type-C boost charger, desktop charger, six-unit charger, vehicle charger.
● QR code manual, software, firmware and other files.
● Reception of the NOAA weather channel, real-time weather warning and Safe travel.
● Multiple function to meet the requirements of amateurs.
● Memory Display Mode / Channel Display Mode
● Password Security Set Up
● Three Selectable TX Power Settings: 5W High/2W Middle / 0.5W Low
● One Watt Powerful Audio Output And Clear Audio From The 36mm Front Speaker
● QRK(Quick Recall Keys)Two User Programmable Keys For Direct Access To Favorite Functions
● Beep Sound On/Off
● Roger Beep Sound
● Channel Announcement
● Over 15 Hours Operating Time
● Versatile Scanning Capabilities: VFO Scan, Memory Scan, Programmable Memory Scan(PMS), Memory Bank Scan, And Dual Receive
● VOX Operation with Optional VOX Earpiece Microphone
● PC Programmable with Optional Programming Cable Transceiver-To-Transceiver Cloning with Optional Cloning Cable FM Broadcast Receiver Equipped
● CTCSS / DCS Operation
● Busy Channel Lock Out (BCLO)
● Battery Saver Function
● Transmitter Time Out Timer ( TOT )
● BIIS PTT ID And Emergency Call
● Surveillance Function
● IP54 and MIL-STD-810 rugged construction
● BNC type antenna connector (Optional)
● Automatic repeater function (Optional)
● Repeater lockout and busy channel lockout
● Transceiver-to-transceiver cloning (Optional)
● Direct keypad frequency entry
● DTMF autodial memories
● Auto power off
● Wide/narrow channel spacing
